Brand – Balluff
Price
$740.00
Type : BOS008E
- Lead Time : 3-5 days
1 in stock (can be backordered)
Details
BOS 26K-PA-1LHB-S4-C
| Series | 26K |
| Dimension | 17 x 50 x 50 mm |
| Fork opening | N/A |
| Interface | PNP Normally open (NO) PNP Normally closed (NC) |
| Principle of operation | Photoelectric sensor |
| Principle of optical operation | Diffuse sensor, Triangulation |
| Special optical feature | Background suppression |
| Beam characteristic | Focus, typical at 80 mm |
| Light type | Laser Red light |
| Light spot size | Ø 0.1 mm at focal point |
| Range | 30…150 mm |
| Connection | Connector, M12x1-Male, 4-pin |
| Housing material | ABS |
| Material sensing surface | PMMA |
| Operating voltage Ub | 10…30 VDC |
| Approval/Conformity | cULus CE UKCA WEEE |
Downloads
| Datasheet | Download |
